TH-0580 Camera Tracking Controller

TH-0580 Camera Tracking Controller

SYMBOL: TH-0580

Price on request
availability: large number
print

Product description


Features
* Built-in video switching matrix (8 input 1 output, can be extended)
* Single-camera has up to 512 position tracking control points. Can be cascade circuit.
* Supports two kinds of high-speed cloud ball protocol. (Pelco_D baud rate 9600, VISCA baud rate 9600)
* CPU communicate with external devices like the computer or video switch matrix via RS-232 I (or RS-485); with a linkage control.
* The high-speed tracking ball tracks all the last-open microphone position; when the last-opened microphone is turned off, the high-speed tracking ball return to the default point, when all in attendance are closed, the camera automatically reset to the standby position.
* Being detached from the computer, camera position can be defaulted through the host panel buttons or through infrared remote control device.

Technical data

 Cameras
≤ 8
Power Supply ~230 V/50 Hz
VIDEO Inputs 8 x BNC Fem
 VIDEO Output 1 x BNC Fem
PC Port  RS 232
Conference Controller Port RJ 45
 Cameras Port RS 485
Power Consumption 10 W
 Dimensions 19"/1U
Weight 2,7 kg

Documents for download
